Name: BSY MACHINERY
Tel: +86 13573702515
Fax: +86-631-5921397
E-mail: info@baishengyuan.com.cn
Add: No.642-5# Qilu Avenue Weihai City Shandong China
Skype: WATERSURFACE0631
QQ:
917669496

Shandong Baishengyuan established in 1956,develop from Weihai Wood-mac factory,deveotes into service professional veneer,plywood and timber man;to be NO.1 in China and focus rank top serious in Asia and World.

"/3 series"SL1350/3;SL2000/3;SL2600/3. Why?--This serious equip CNC system; Double servo-motors,correspond knife gap (related with veneer thickness) and knife carriage;Strong hydraulic station;Cast iron machine body; Double Gear-box transmission in driven rollers in stead of chains;First-class electrical parts be used within electrical cabinet;Meet hard-wood peeling;Super-friendly operator touching panel board,peeling veneer thickness automatic change ,no need traditional manual way to change knife gap;ETC.


30% DOWN PAYMENT BY T/T, THE BALANCE 70% AFTER MACHINES DONE BEFORE SHIPMENT DELIVERY.OR AT SIGHT 70% L/C.DELIVERY TIME AROUND 45 DAYS (EXCEPT VENEER LINE AND PLYWOOD LINE) ONCE RECEIVED DOWN PAYMENT.-IF WITHOUT SPECIAL NOTICE THE OFFERS FROM US ALWAYS KEEP VALIDITY TIME.
How many Baishengyuan company in woodworking machines of China?Only one,so you should check with us if your machine or offer original of us.

FOR TICKETS, 70$-100$/DAY AS SALARY(SATURDAY&SUNDAY WORKING DOUBLE SALARY,IF NOT WORK,70-100$/DAY), FOOD, LIVING, WORKING DAYS ACCORDING MACHINES QUANTITY.- MECHANICAL PARTS AND ELECTRICAL PARTS WARRANTY PERIOD IS SEPERATE SIX-MONTH AND ONE YEAR AFTER INSTALLATION.

We are looking for long-term value added agents,not a simple trader only.Once user face fault, your team should with ability of Vanguard in machines engineering.

Of Course.We have above markets users over dozens;correspond woodworking machines CE certification.

Weihai-linares is a joint venture between Shandong Baishengyuan and Argentina Linares since the year 2004.Mainly export to USA,Japan,Latin Areas,West-euro areas.In recent years start sale in China and other countries.More details visit www.weihai-linares.com


its related to veneer thickness) in line ? Normally, in advance of spindle rotary lathe departure our factory,the knife gap have
been set in good positon.Most customer meet this question always in peeling blade change,
have some query,how to make the knife gap in good horizontal line level,here we are organize a small course from three points
(knife holder’s micro screw, nose bar’s micro screw,
two valves on hydraulic station),combine photo and drawing.
1): As machine equip hydraulic system,press the button on control panel, the knife holder opening&close freely,
take out knife holder&blade together;at the bottom of knife holder
you will find some screws for refine adjust.
2):Back the nose bar,on knife carriage,you will find groups of screws also,they are correspond to nose bar for refine adjust.
3): After working for a period,inside of these double valves must be keep clean,they are related to hydraulic pressure
affected the gap adjust.
